Tweeter

1" (25 mm) Titanium soft dome

1" (25 mm) Titanium soft dome

Woofer

6.5" (165 mm) Graphite Cone, Rubber Surround

8" (203 mm) Graphite Cone, Rubber Surround

Frequency Range+/-3

46 Hz -20k Hz

40 Hz -20k Hz

Power Handing RMS

80 W program , 40 W ( IEEE 219 )

100 W program , 50 W ( IEEE 219 )

Sensitivity

85 dB

85 dB

Taps

N/A

N/A

Impedance

8 ohms

8 ohms

Termination

Standard pressed connector

Standard pressed connector

Included Accessories

Cuout template grille

Cuout template grille

Dimensions

14.21" x 9.17"  x 3.93" (361mm x 233mm x 100mm)

15.75" x 10.35"  x 3.93" (400mm x 263mm x100mm )

Cut out diameter

12.99" x 7.95" (330mm x 202mm )

14.72" x 9.11" (374mm x 231.5mm )

Certifications

N/A

N/A
